Adjustable Steel Props Scaffolding Shoring Props for Concrete Construction
Heavy Duty Adjustable Scaffolding Steel Formwork Construction Jack designed for reliable performance in concrete construction applications.
Key Features & Benefits
- Robust construction with bottom plate, outer tube, inner tube, swivel nut, cotter pin, upper plate and accessories
- Simple and flexible structure for easy assembly and disassembly
- Fully adjustable height through inner tube extension and retraction
- Reusable design with recyclable materials for sustainable construction
- Versatile application for various construction height requirements
Product Specifications
| Item |
Adjustable steel prop |
| Type |
Heavy duty / Light duty |
| Inner pipe/Outer pipe |
48/60mm, 40/48mm, 48/56mm |
| Pipe thickness |
1.6-4.0mm |
| Normal length |
1.7-3m / 2.1-3.8m / 2.2-4m / 2.7-5m |
| Surface treatment |
Pre-galvanized/painted/powder coated/hot dip galvanized |
| Material |
Q235 |
| Application |
Construction |
| Packing |
Bundle |
| Certificate |
SGS |
| Production Capacity |
1500 tons per month |
Light Duty Prop Specifications
Spanish Prop
| Min Height |
Max Height |
Inner Tube |
Outer Tube |
Tube Thk |
| 0.6m |
1.1m |
40mm |
48mm |
1.6-2.5mm |
| 0.8m |
1.4m |
40mm |
48mm |
1.6-2.5mm |
| 1.6m |
2.9m |
40mm |
48mm |
1.6-2.5mm |
| 1.8m |
3.2m |
40mm |
48mm |
1.6-2.5mm |
| 2.0m |
3.6m |
40mm |
48mm |
1.6-2.5mm |
| 2.2m |
4.0m |
40mm |
48mm |
1.6-2.5mm |
Italian Prop
| Min Height |
Max Height |
Inner Tube |
Outer Tube |
Tube Thk |
| 1.6m |
2.9m |
48mm |
56mm |
1.6-2.5mm |
| 1.8m |
3.2m |
48mm |
56mm |
1.6-2.5mm |
| 2.0m |
3.5m |
48mm |
56mm |
1.6-2.5mm |
| 2.0m |
3.6m |
48mm |
56mm |
1.6-2.5mm |
| 2.2m |
4.0m |
48mm |
56mm |
1.6-2.5mm |
Heavy Duty Prop Specifications
Middle East Prop
| Min Height |
Max Height |
Inner Tube |
Outer Tube |
Tube Thk |
| 1.6m |
2.9m |
48mm |
60mm |
1.6-4.0mm |
| 1.8m |
3.2m |
48mm |
60mm |
1.6-4.0mm |
| 2.0m |
3.5m |
48mm |
60mm |
1.6-4.0mm |
| 2.0m |
3.6m |
48mm |
60mm |
1.6-4.0mm |
| 2.2m |
4.0m |
48mm |
60mm |
1.6-4.0mm |
| 3.0m |
5.0m |
48mm |
60mm |
1.6-4.0mm |
| 3.5m |
6.0m |
48mm |
60mm |
1.6-4.0mm |
Product Gallery
Complete Accessory System
We provide a complete set of steel prop accessories including Top Plate, Base Plate, Inner pipe, Outer pipe, Prop, and more.
Adjustable Prop Sleeve
|
Parameter |
Value |
Parameter |
Value |
| Diameter |
60mm/76mm |
Material |
Q235 |
| Length |
195-400mm |
Surface Finish |
Galvanized or black |
| Thickness |
2.5-4.0mm |
Color |
Gold, Silver or Black |
| Hole Size |
14*150mm
15*160mm |
Application |
Prop adjusting |
| Thread |
6.35mm |
Related Items |
Prop nut, Base plate, G pin, etc. |
| Thread Type |
Threading or Rolling |
Packing |
Bags or Pallets |
Adjustable Prop Sleeve Handle Nut
|
Parameter |
Value |
Parameter |
Value |
| Diameter |
60mm, 76mm |
Material |
Ductile Iron Casting |
| Weight |
250g, 560g, 780g and etc. |
Surface Finish |
Galvanized or as Nature |
| Handle |
with or not |
Color |
Silver, Gold or Black |
| Thread |
6.35mm |
Packing |
bags or pallet |
| Thread Type |
Rolling or Casting |
Related Products |
Prop Sleeve, Prop Support Pin and etc. |
Adjustable Shoring Prop Support Pin
| Picture |
Type |
Diameter |
Material |
Surface Finish |
|
G Pin |
11mm, 12mm, 14mm, 16mm |
Q235 or 45# Steel |
Galvanized or as Nature |
|
Chain Pin |
11mm, 12mm |
Q235 or 45# Steel |
Galvanized or as Nature |
|
Wire Pin |
11mm, 12mm |
Q235 or 45# Steel |
Galvanized or as Nature |
Other Support Parts
| Picture |
Item Detail |
Size |
Surface Finish |
|
Fork Head |
2.2kgs, 2.5kgs |
Galvanized |
|
Tripod |
5.5kgs |
Galvanized or Painted |
|
Base Plate |
120x120x5mm, 140x140x8mm, Flower Type and Square Type |
Galvanized or as Nature |
All parts above available in OEM sizes and designs to meet your specific requirements.
Quality Assurance & Global Reach
Our entire product range is designed in compliance with international quality standards. Available in varied grades, dimensions, finishes and specifications, these products efficiently cater to diverse industrial needs. We offer customization services according to client specifications and also provide Scaffolding Props and Formwork Accessories including Tie Rod, Tie Nut, Water Stop, and more.
All products undergo rigorous quality checks to ensure flawless performance. Our product range is highly demanded across Australia/NZ, USA, Mexico, Poland, UK, Korea, South/West Africa and Middle East.
Send us your adjustable steel props requirements to get a competitive price by importing directly.
